Butt Weld Elbow
Description
We can categorize pipe fitting by different methods. For example, by material we can say: carbon steel pipe fitting, stainless steel fitting, and by the way of connection, there are butt-welded pipe fitting, socket pipe fitting and threaded fitting.
Butt Weld Elbow Specification
1. Butt-Welded Steel Elbow
2. Material: Carbon steel and stainless steel, including: ASTM A234-WPB; A420-WPL6.A234-WP12.A234-WP11; A234-WP5.A403-WP304. A403-WP304L.A403-WP316.A403-WP316L
3. Type: 45o Butt-Welded Steel Elbow;90o Butt-Welded Elbow(both LR and SR) and 180 Butt-Welded Elbow ;
4. Size: 1/2"-48" (DN15-DN1200)
5. Pressure: Sch5-Sch160XXS
6.Standard: GB 12459GB/T 13401SH 3408SH 3409HG/T 21635HG/T 21631SY/T 0510ASME B16.9
Application
All steel pipe fittings are used as accessories for steel pipe. To connected carbon steel pipe or stainless steel pipe which are widely used in Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc.
Note: For steel pipe fitting OD≥28we can only do welded ones which are made of welded steel pipe
|
Nominal Diameter |
Outside Diameter
at Bevel |
Center to End |
Center to Center |
Back to Face |
|
45oElbow |
90oElbow |
180oElbow |
|
B |
A |
O |
K |
|
DN |
NPS |
Series A |
Series B |
Long
Radius |
Long
Radius |
Short
Radius |
Long
Radius |
Short
Radius |
Long
Radius |
Short
Radius |
|
15 |
1/2 |
21.3 |
18 |
16 |
38 |
- |
76 |
- |
48 |
- |
|
20 |
3/4 |
26.9 |
25 |
19 |
38 |
- |
76 |
- |
51 |
- |
|
25 |
1 |
33.7 |
32 |
22 |
38 |
25 |
76 |
51 |
56 |
41 |
|
32 |
1.1/4 |
42.4 |
38 |
25 |
48 |
32 |
95 |
64 |
70 |
52 |
|
40 |
1.1/2 |
48.3 |
45 |
29 |
57 |
38 |
114 |
76 |
83 |
62 |
|
50 |
2 |
60.3 |
57 |
35 |
76 |
51 |
152 |
102 |
106 |
81 |
|
65 |
2.1/2 |
76.1(73) |
76 |
44 |
95 |
64 |
190 |
127 |
132 |
100 |
|
80 |
3 |
88.9 |
89 |
51 |
114 |
76 |
229 |
152 |
159 |
121 |
|
90 |
3.1/2 |
101.6 |
- |
57 |
133 |
89 |
267 |
178 |
184 |
140 |
|
100 |
4 |
114.3 |
108 |
64 |
152 |
102 |
305 |
203 |
210 |
159 |
|
125 |
5 |
139.7 |
133 |
79 |
190 |
127 |
381 |
254 |
262 |
197 |
|
150 |
6 |
168.3 |
159 |
95 |
229 |
152 |
457 |
305 |
313 |
237 |
|
200 |
8 |
219.1 |
219 |
127 |
305 |
203 |
610 |
406 |
414 |
313 |
|
250 |
10 |
273.0 |
273 |
159 |
381 |
254 |
762 |
508 |
518 |
391 |
|
300 |
12 |
323.9 |
325 |
190 |
457 |
305 |
914 |
610 |
619 |
467 |
|
350 |
14 |
355.6 |
377 |
222 |
533 |
356 |
1067 |
711 |
711 |
533 |
|
400 |
16 |
406.4 |
426 |
254 |
610 |
406 |
1219 |
813 |
813 |
610 |
|
450 |
18 |
457.2 |
478 |
286 |
686 |
457 |
1372 |
914 |
914 |
686 |
|
500 |
20 |
508.0 |
529 |
318 |
762 |
508 |
1524 |
1016 |
1016 |
762 |
|
550 |
22 |
559 |
- |
343 |
838 |
559 |
1676 |
1118 |
1118 |
838 |
|
600 |
24 |
610 |
630 |
381 |
914 |
610 |
1829 |
1219 |
1219 |
914 |
|
650 |
26 |
660 |
- |
406 |
991 |
660 |
1982 |
1320 |
- |
- |
|
700 |
28 |
711 |
720 |
438 |
1067 |
711 |
2134 |
1422 |
- |
- |
|
750 |
30 |
762 |
- |
470 |
1143 |
762 |
2286 |
1524 |
- |
- |
|
800 |
32 |
813 |
820 |
502 |
1219 |
813 |
2438 |
1626 |
- |
- |
|
850 |
34 |
864 |
- |
533 |
1295 |
864 |
2590 |
1728 |
- |
- |
|
900 |
36 |
914 |
920 |
565 |
1372 |
914 |
2744 |
1828 |
- |
- |
|
950 |
38 |
965 |
- |
600 |
1448 |
965 |
2896 |
1930 |
- |
- |
|
1000 |
40 |
1016 |
1020 |
632 |
1524 |
1016 |
3048 |
2032 |
- |
- |
|
1050 |
42 |
1067 |
- |
660 |
1600 |
1067 |
3200 |
2134 |
- |
- |
|
1100 |
44 |
1118 |
1120 |
695 |
1676 |
1118 |
3352 |
2236 |
- |
- |
|
1150 |
46 |
1168 |
- |
727 |
1753 |
1168 |
3506 |
2336 |
- |
- |
|
1200 |
48 |
1220 |
1220 |
759 |
1829 |
1219 |
3658 |
2440 |
- |
- |
|
