Butt Welded Steel Reducer
Description
You can also call steel reducer as reducing pipe but much shorter. There are concentric steel reducer and eccentric reducers.
Specification
1.Butt-Welded Steel Reducer
2.Standard and Material: Carbon steel reducer including: ASTM A234-WPB; A420-WPL6.A234-WP12.A234-WP11; A234-WP5.A403-WP304. Stainless steel reducer including: A403-WP304L.A403-WP316.A403-WP316L.
3.Butt Welded Steel Reducer Type: concentric reducer; eccentric reducer
4. Size: 3/4×1/2(DN20xDN15);48X40(1200X1000)
5.Standard: GB 12459GB/T 13401SH 3408SH 3409HG/T 21635HG/T 21631SY/T 0510ASME B16.9
Application:
Steel pipe fittings are used as accessories for steel pipes. Widely used in city water supply systems, food and beverage industry, medicine Industry and so on
Nominal Diameter |
Outside Diameter |
End to End |
|
D1*D2 |
|
DN |
NPS |
A |
B |
H |
|
20×15 |
3/4×1/2 |
26.9×21.3 |
25×18 |
38 |
|
20×10 |
3/4×3/8 |
26.9×17.3 |
25×14 |
38 |
|
25×20 |
1×3/4 |
33.7×26.9 |
32×25 |
51 |
|
25×15 |
1×1/2 |
33.7×21.3 |
32×18 |
51 |
|
32×25 |
1.1/4×1 |
42.4×33.7 |
38×32 |
51 |
|
32×20 |
1.1/4×3/4 |
42.4×26.9 |
38×25 |
51 |
|
32×15 |
1.1/4×1/2 |
42.4×21.3 |
38×18 |
51 |
|
40×32 |
1.1/2×1.1/4 |
48.3×42.4 |
45×38 |
64 |
|
40×25 |
1.1/2×1 |
48.3×33.7 |
45×32 |
64 |
|
40×20 |
1.1/2×3/4 |
48.3×26.9 |
45×25 |
64 |
|
40×15 |
1.1/2×1/2 |
48.3×21.3 |
45×18 |
64 |
|
50×40 |
2×1.1/2 |
60.3×48.3 |
57×45 |
76 |
|
50×32 |
2×1.1/4 |
60.3×42.4 |
57×38 |
76 |
|
50×25 |
2×1 |
60.3×33.7 |
57×32 |
76 |
|
50×20 |
2×3/4 |
60.3×26.9 |
57×25 |
76 |
|
65×50 |
2.1/2×2 |
73.0×60.3 |
76×57 |
89 |
|
65×40 |
2.1/2×1.1/2 |
73.0×48.3 |
76×45 |
89 |
|
65×32 |
2.1/2×1.1/4 |
73.0×42.4 |
76×38 |
89 |
|
