Socket Weld Elbow
Description
Socket Welding Fittings are also widely used for connecting. We supply forged socket steel fittings and for Socket elbows we have 90oand 45oelbow, material can be both carbon steel and stainless steel.
Specification
1. Socket Weld Elbow
2. Material: Carbon steel and stainless steel, including: A105, 20#, 16Mn, 1cr5mo ,304, F11, F22, F5, 316L, P.R304 3163.
3. Stainless Socket Weld FittingType: 45oSocket Elbow;90oSocket Elbow;
4. Size: 1/8"-4 (DN6-DN100)
5.Pressure: 3000LB-9000LB, Sch80-SchXXS
6.Standard: GB/T14383SH 3410HG/T 21634ASME B 16.11JIS B2316
Application
All Stainless Socket Weld Fitting are used as accessories for steel pipes. To connected carbon steel pipes or stainless steel pipes which are widely used in Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc.
|
Nominal Pipe Size |
Depth of Socket |
Wall Thickness |
Center to Bottom of Socket |
|
A |
|
C min |
90oElbow Tee Cross |
45oElbow |
|
DN |
NPS |
J min |
SCH80
3000 |
SCH160
6000 |
XXS
9000 |
SCH80
3000 |
SCH160
6000 |
XXS
9000 |
SCH80
3000 |
SCH160
6000 |
XXS
9000 |
6
8
10 |
1/8
1/4
3/8 |
10
10
10 |
3.2
3.8
4.0 |
4.0
4.6
5.1 |
--
--
-- |
11
11
14 |
11
14
16 |
--
--
-- |
8
8
8 |
8
8
11 |
--
--
-- |
15
20
25 |
1/2
3/4
1 |
10
13
13 |
4.5
5.0
5.6 |
5.6
7.0
7.9 |
9.4
9.8
11.4 |
16
19
22 |
19
22
27 |
25
29
32 |
11
13
14 |
13
14
18 |
16
19
21 |
32
40
50 |
11/4
11/2
2 |
13
13
16 |
6.3
6.3
7.0 |
7.9
8.9
11.0 |
12.2
12.7
13.9 |
27
32
38 |
32
38
41 |
35
38
54 |
18
21
25 |
21
25
29 |
22
25
29 |
65
80
100 |
21/2
3
4 |
16
16
19 |
8.9
10.0
10.7 |
12.5
13.8
-- |
--
--
-- |
41
57
67 |
57
64
-- |
--
--
-- |
29
32
41 |
32
35
-- |
--
--
-- |
1. The above list shows sizes of the same parts of Socket Welding (SW) fittings. The sizes of different codes pipes, socket diameter d1 and bore diameter d2 refer to the list of the pipe outside diameter, socket diameter and bore diameter of SW fittings.
2. As to the reducing fittings, size of the bore diameter d2 applies to the relevant size d2 of the reducing nominal pipe size, size of center to the bottom of socket A is same to the straight fittings.
3. Average of socket wall thickness around periphery shall be no less than listed values. The minimum values are permitted in localized areas.
4. Upper and lower values for each size are the respective maximum and minimum dimensions. |
